Advanced Radio Frequency Applicators for Thermal Magnetic Resonance Theranostics of Brain Tumors.

Abstract

Thermal Magnetic Resonance (ThermalMR) is a theranostic concept that combines diagnostic magnetic resonance imaging (MRI) with targeted thermal therapy in the hyperthermia (HT) range using a radiofrequency (RF) applicator in an integrated system. ThermalMR adds a therapeutic dimension to a diagnostic MRI device. Focused, targeted RF heating of deep-seated brain tumors, accurate non-invasive temperature monitoring and high-resolution MRI are specific requirements of ThermalMR that can be addressed with novel concepts in RF applicator design. This work examines hybrid RF applicator arrays combining loop and self-grounded bow-tie (SGBT) dipole antennas for ThermalMR of brain tumors, at magnetic field strengths of 7.0 T, 9.4 T and 10.5 T. These high-density RF arrays improve the feasible transmission channel count, and provide additional degrees of freedom for RF shimming not afforded by using dipole antennas only, for superior thermal therapy and MRI diagnostics. These improvements are especially relevant for ThermalMR theranostics of deep-seated brain tumors because of the small surface area of the head. ThermalMR RF applicators with the hybrid loop+SGBT dipole design outperformed applicators using dipole-only and loop-only designs, with superior MRI performance and targeted RF heating. Array variants with a horse-shoe configuration covering an arc (270°) around the head avoiding the eyes performed better than designs with 360° coverage, with a 1.3 °C higher temperature rise inside the tumor while sparing healthy tissue. Our EMF and temperature simulations performed on a virtual patient with a clinically realistic intracranial tumor provide a technical foundation for implementation of advanced RF applicators tailored for ThermalMR theranostics of brain tumors.

AI evidence extraction

Main findings

Hybrid RF applicator arrays combining loop and self-grounded bow-tie (SGBT) dipole antennas for ThermalMR at 7.0 T, 9.4 T and 10.5 T outperformed dipole-only and loop-only designs, with superior MRI performance and targeted RF heating in simulations. A 270° horse-shoe configuration avoiding the eyes performed better than 360° coverage, producing a 1.3 °C higher temperature rise inside the tumor while sparing healthy tissue.

Outcomes measured

• MRI performance
• Targeted RF heating/temperature rise in tumor
• Healthy tissue sparing
• EMF and temperature simulation metrics
• RF shimming degrees of freedom
• Transmission channel count feasibility

Limitations

• Findings are based on EMF and temperature simulations on a virtual patient rather than clinical or experimental measurements.
• No RF frequency, SAR, or exposure duration parameters are reported in the abstract.

{
    "study_type": "engineering",
    "exposure": {
        "band": "RF",
        "source": "MRI/thermal therapy RF applicator (ThermalMR)",
        "frequency_mhz": null,
        "sar_wkg": null,
        "duration": null
    },
    "population": "Virtual patient with a clinically realistic intracranial tumor (simulation)",
    "sample_size": null,
    "outcomes": [
        "MRI performance",
        "Targeted RF heating/temperature rise in tumor",
        "Healthy tissue sparing",
        "EMF and temperature simulation metrics",
        "RF shimming degrees of freedom",
        "Transmission channel count feasibility"
    ],
    "main_findings": "Hybrid RF applicator arrays combining loop and self-grounded bow-tie (SGBT) dipole antennas for ThermalMR at 7.0 T, 9.4 T and 10.5 T outperformed dipole-only and loop-only designs, with superior MRI performance and targeted RF heating in simulations. A 270° horse-shoe configuration avoiding the eyes performed better than 360° coverage, producing a 1.3 °C higher temperature rise inside the tumor while sparing healthy tissue.",
    "effect_direction": "benefit",
    "limitations": [
        "Findings are based on EMF and temperature simulations on a virtual patient rather than clinical or experimental measurements.",
        "No RF frequency, SAR, or exposure duration parameters are reported in the abstract."
    ],
    "evidence_strength": "insufficient",
    "confidence": 0.7399999999999999911182158029987476766109466552734375,
    "peer_reviewed_likely": "yes",
    "keywords": [
        "ThermalMR",
        "theranostics",
        "brain tumors",
        "hyperthermia",
        "radiofrequency applicator",
        "RF heating",
        "MRI",
        "RF shimming",
        "loop antenna",
        "self-grounded bow-tie dipole",
        "SGBT",
        "EMF simulation",
        "temperature simulation",
        "7.0 T",
        "9.4 T",
        "10.5 T"
    ],
    "suggested_hubs": []
}
