The Effects of mmW and THz Radiation on Dry Eyes: A Finite-Difference Time-Domain (FDTD) Computational Simulation Using XFdtd
Abstract
The Effects of mmW and THz Radiation on Dry Eyes: A Finite-Difference Time-Domain (FDTD) Computational Simulation Using XFdtd Foroughimehr N, Vilagosh Z, Yavari A, Wood A. The Effects of mmW and THz Radiation on Dry Eyes: A Finite- Difference Time-Domain (FDTD) Computational Simulation Using XFdtd. Sensors (Basel). 2023 Jun 24;23(13):5853. doi: 10.3390/s23135853. Abstract The importance of investigating the health effects of RF radiation on the cornea cannot be overstated. This study aimed to address this need by utilizing a mathematical simulation to examine the absorption of millimeter wave (mmW) and terahertz (THz) waves by the cornea, considering both normal and pathological conditions. The simulation incorporated variations in tear film thickness and hydration levels, as these factors play a crucial role in corneal health. To assess the impact of RF radiation on the cornea, the study calculated temperature rises, which indicate heating effects for both dry and normal eyes. XFdtd, a widely used commercial software based on the Finite-Difference Time Domain (FDTD) method, was employed to evaluate the radiation absorption and resulting temperature changes. The outcomes of this study demonstrated a crucial finding, i.e., that changes in the water ratio and thickness of the tear film, which are associated with an increased risk of dry eye syndrome, directly impact the absorption of mmW and THz waves by the cornea. This insight provides valuable evidence supporting the interconnection between tear film properties and the vulnerability of the cornea to RF radiation. Conclusions With the advances in 5G technology and the future development of potential 6G operating systems, there is growing anticipation for higher frequencies reaching up to 4 THz in the electromagnetic (EM) spectrum. With the increase in frequency, reaching significantly beyond 6 GHz, the penetration depth decreases, resulting in a more significant deposition of EM energy within superficial tissues with a high water content, such as the cornea. In this study, we analyzed the power density and electric field distributions and the resulting temperature rise in the cornea when exposed to plane waves ranging from 30 GHz to 0.5 THz. Our findings indicate that the impact of mmW and THz radiation on the cornea may be slightly more noticeable in the case of dry eyes. However, further investigation is needed through in vivo studies to gain deeper insights into these effects and their potential implications. Open access paper: mdpi.com
AI evidence extraction
Main findings
Using FDTD simulations (XFdtd) of plane-wave exposure from 30 GHz to 0.5 THz, the study reports that tear film thickness and water ratio (hydration) affect modeled absorption and temperature rise in the cornea. The authors state the impact of mmW/THz radiation on the cornea may be slightly more noticeable for dry-eye conditions than normal-eye conditions, and call for in vivo studies.
Outcomes measured
- Corneal RF absorption (modeled)
- Power density distribution (modeled)
- Electric field distribution (modeled)
- Corneal temperature rise (modeled heating)
- Differences between dry-eye vs normal-eye tear film conditions (modeled)
Limitations
- Computational (FDTD) simulation rather than in vivo or clinical measurements
- Exposure described as plane waves; real-world exposure scenarios may differ
- Authors note further investigation is needed through in vivo studies
Suggested hubs
-
5g-policy
(0.52) The paper discusses higher-frequency exposures relevant to 5G/6G (mmW/THz) and superficial tissue energy deposition.
View raw extracted JSON
{
"publication_year": 2023,
"study_type": "engineering",
"exposure": {
"band": "mmWave",
"source": "plane wave (computational simulation)",
"frequency_mhz": null,
"sar_wkg": null,
"duration": null
},
"population": null,
"sample_size": null,
"outcomes": [
"Corneal RF absorption (modeled)",
"Power density distribution (modeled)",
"Electric field distribution (modeled)",
"Corneal temperature rise (modeled heating)",
"Differences between dry-eye vs normal-eye tear film conditions (modeled)"
],
"main_findings": "Using FDTD simulations (XFdtd) of plane-wave exposure from 30 GHz to 0.5 THz, the study reports that tear film thickness and water ratio (hydration) affect modeled absorption and temperature rise in the cornea. The authors state the impact of mmW/THz radiation on the cornea may be slightly more noticeable for dry-eye conditions than normal-eye conditions, and call for in vivo studies.",
"effect_direction": "mixed",
"limitations": [
"Computational (FDTD) simulation rather than in vivo or clinical measurements",
"Exposure described as plane waves; real-world exposure scenarios may differ",
"Authors note further investigation is needed through in vivo studies"
],
"evidence_strength": "low",
"confidence": 0.7399999999999999911182158029987476766109466552734375,
"peer_reviewed_likely": "yes",
"stance": "concern",
"stance_confidence": 0.61999999999999999555910790149937383830547332763671875,
"summary": "This engineering study used FDTD (XFdtd) simulations to model corneal absorption and temperature rise from plane-wave exposures spanning 30 GHz to 0.5 THz. The simulations varied tear film thickness and hydration to represent normal versus dry-eye conditions. The authors report that tear film properties directly influence modeled absorption, and that effects may be slightly more noticeable for dry eyes, while emphasizing the need for in vivo research.",
"key_points": [
"The work is a computational FDTD simulation of mmW/THz interactions with the cornea using XFdtd.",
"Exposures were modeled as plane waves from 30 GHz to 0.5 THz.",
"The model varied tear film thickness and water ratio to represent normal and pathological (dry-eye) conditions.",
"Outcomes included modeled power density, electric field distributions, and corneal temperature rise.",
"The study reports tear film properties directly affect modeled absorption of mmW/THz energy by the cornea.",
"The authors state effects may be slightly more noticeable in dry-eye conditions and recommend in vivo studies."
],
"categories": [
"5G & New Radio Frequencies",
"Mechanisms & Biophysics",
"Dosimetry & Exposure Modeling",
"Eye & Vision"
],
"tags": [
"Millimeter Waves",
"Terahertz Radiation",
"Cornea",
"Dry Eye Syndrome",
"Tear Film",
"Hydration",
"Finite-Difference Time-Domain",
"XFdtd",
"Plane-Wave Exposure",
"Temperature Rise",
"Power Density",
"Electric Field Distribution",
"RF Absorption",
"5G",
"6G"
],
"keywords": [
"mmW",
"THz",
"cornea",
"dry eye",
"tear film thickness",
"hydration",
"FDTD",
"XFdtd",
"temperature rise",
"absorption",
"30 GHz",
"0.5 THz"
],
"suggested_hubs": [
{
"slug": "5g-policy",
"weight": 0.520000000000000017763568394002504646778106689453125,
"reason": "The paper discusses higher-frequency exposures relevant to 5G/6G (mmW/THz) and superficial tissue energy deposition."
}
],
"social": {
"tweet": "FDTD simulations (XFdtd) modeled corneal absorption and heating from 30 GHz–0.5 THz plane waves, varying tear film thickness/hydration. The study reports tear film properties affect absorption, with effects possibly slightly more noticeable for dry-eye conditions; in vivo studies are needed.",
"facebook": "A computational FDTD (XFdtd) study modeled how mmW/THz plane waves (30 GHz–0.5 THz) are absorbed by the cornea and how this relates to temperature rise. By varying tear film thickness and hydration to represent dry-eye conditions, the authors report tear film properties influence absorption and that effects may be slightly more noticeable for dry eyes, while calling for in vivo research.",
"linkedin": "Engineering/dosimetry paper: FDTD (XFdtd) simulations of corneal exposure to 30 GHz–0.5 THz plane waves examined power density, E-field distributions, and temperature rise under normal vs dry-eye tear film parameters. The authors report tear film thickness/hydration affects modeled absorption, with potentially slightly more noticeable effects for dry eyes, and recommend in vivo validation."
}
}
