A Compact Button Antenna with Dual-Band and Dual-Polarization for Wearable Body Area Networks.

PAPER pubmed Micromachines 2025 Engineering / measurement Effect: no_effect Evidence: Insufficient

Read original paper → DOI: 10.3390/mi17010028 PMID: 41597809 Evidence Lab

Abstract

This paper presents a compact, dual-band, dual-polarization button antenna for Wireless Body Area Networks (WBANs) that operates in the 2.45 GHz and 5.8 GHz Industrial, Scientific, and Medical (ISM) bands. The antenna is engineered in the lower band from 2.33 to 2.8 GHz (18.3% fractional bandwidth) as a linearly polarized, top-loaded monopole, which provides an omnidirectional radiation pattern for on-body communication. In contrast, it functions as a cross-dipole in the higher band, achieving a fractional bandwidth of 66.4% (4.8-9.57 GHz) and a 3 dB axial ratio (AR) bandwidth of 57.4%, producing a broadside radiation with circular polarization for off-body communications. Prototype measurements in both free-space and on-body settings confirm the antenna's robust performance, successfully validating its dual-band operation, dual-polarization characteristics. Furthermore, Specific Absorption Rate (SAR) simulations conducted on a human model demonstrate that the values are significantly below the established safety limits, confirming the antenna's suitability for practical wearable applications.

AI evidence extraction

At a glance

Study type

Engineering / measurement

Effect direction

no_effect

Population

—

Sample size

—

Exposure

RF wearable (WBAN) antenna

Evidence strength

Insufficient

Confidence: 74% · Peer-reviewed: yes

Main findings

A compact button antenna for WBANs is reported to operate in the 2.45 GHz and 5.8 GHz ISM bands, with measured free-space and on-body tests supporting dual-band and dual-polarization performance. SAR simulations on a human model were reported as significantly below established safety limits.

Outcomes measured

Antenna performance (dual-band operation, bandwidth, polarization, radiation patterns) in free-space and on-body settings
Specific Absorption Rate (SAR) simulation results on a human model relative to safety limits

Limitations

No numeric SAR values are provided in the abstract.
SAR results are described as simulations on a human model; details of model, assumptions, and standards/limits are not specified in the abstract.
No sample size or participant details are provided for the on-body measurements.

Suggested hubs

occupational-exposure (0.1)
Wearable/on-body RF device context, but not an occupational study.

View raw extracted JSON

{
    "study_type": "engineering",
    "exposure": {
        "band": "RF",
        "source": "wearable (WBAN) antenna",
        "frequency_mhz": null,
        "sar_wkg": null,
        "duration": null
    },
    "population": null,
    "sample_size": null,
    "outcomes": [
        "Antenna performance (dual-band operation, bandwidth, polarization, radiation patterns) in free-space and on-body settings",
        "Specific Absorption Rate (SAR) simulation results on a human model relative to safety limits"
    ],
    "main_findings": "A compact button antenna for WBANs is reported to operate in the 2.45 GHz and 5.8 GHz ISM bands, with measured free-space and on-body tests supporting dual-band and dual-polarization performance. SAR simulations on a human model were reported as significantly below established safety limits.",
    "effect_direction": "no_effect",
    "limitations": [
        "No numeric SAR values are provided in the abstract.",
        "SAR results are described as simulations on a human model; details of model, assumptions, and standards/limits are not specified in the abstract.",
        "No sample size or participant details are provided for the on-body measurements."
    ],
    "evidence_strength": "insufficient",
    "confidence": 0.7399999999999999911182158029987476766109466552734375,
    "peer_reviewed_likely": "yes",
    "keywords": [
        "wearable",
        "WBAN",
        "button antenna",
        "2.45 GHz",
        "5.8 GHz",
        "ISM band",
        "dual-band",
        "dual-polarization",
        "circular polarization",
        "on-body",
        "SAR"
    ],
    "suggested_hubs": [
        {
            "slug": "occupational-exposure",
            "weight": 0.1000000000000000055511151231257827021181583404541015625,
            "reason": "Wearable/on-body RF device context, but not an occupational study."
        }
    ]
}

AI can be wrong. Always verify against the paper.

AI-extracted fields are generated from the abstract/metadata and may be incomplete or incorrect. This content is for informational purposes only and is not medical advice.
