3D GIS for surface modelling of magnetic fields generated by overhead power lines and their validation in a complex urban area.
This paper presents a 3D GIS approach to model magnetic fields from overhead high-voltage power lines while accounting for terrain relief and cable catenary. The model was validated against extensive field measurements in two complex urban environments and showed good agreement with measured values, though accuracy differed by setting. The authors emphasize that high-resolution terrain elevation data were essential for the model’s performance and suggest the resulting continuous MF surfaces could support future environmental and public health studies.
Key points
- The study addresses modeling of residential ELF magnetic field exposure from overhead high-voltage power lines in complex terrain.
- A 3D GIS workflow (ArcGIS) is used to compute MF intensity surfaces at real ground elevation.
- Magnetic field calculations are based on a series expansion of the Biot–Savart law for an infinite rectilinear conductor with variable height following cable catenary.
- Validation used 69 control points (1035 measurements) in a free urban area and 28 points (420 measurements) in a built-up area with complex relief.
- Reported validation metrics indicate good fit overall, with different error levels across the two areas.
- The model correctly classified 86% of points according to usual exposure percentiles.
- A 5 m resolution digital terrain model is described as indispensable for achieving good performance.
- The output is a continuous surface of MF values intended to improve exposure assessment for future studies.
