Standards: Exposure Limits for Brief High Intensity Pulses of Radiofrequency Energy Between 6 and 300 GHz

Abstract

Category: Environmental Health Physics Tags: RF-EMF, exposure limits, pulsed radiofrequency, thermal effects, ICNIRP, IEEE guidelines, MIMO antennas DOI: 10.1109/access.2025.3592532 URL: ieeexplore.ieee.org Overview This Standards paper examines the exposure limits defined by the International Commission on Nonionizing Radiation Protection (ICNIRP) and the IEEE (C95.1-2019) concerning "brief exposures" to radiofrequency electromagnetic fields (RF-EMF), especially when exposures fluctuate significantly within the 6-minute averaging period specified in the current guidelines. Relevant Exposure Scenarios - Cellular base stations using MIMO antennas with beamforming technology, which sweep beams dynamically across the service area. - Exposure to pulsed RF-EMF with high peak power and low duty cycles. Findings - Both ICNIRP and IEEE limits for brief RF-EMF exposures between 6 and 300 GHz were assessed with numerical and analytical approaches using a one-dimensional thermal tissue model. - The study analyzed skin heating effects for both rectangular RF-EMF pulses (sudden exposure) and impulsive energy events. - The research revealed that these guidelines provide varying levels of protection against transient skin heating—with IEEE guidelines being notably more conservative than ICNIRP's. - The paper proposes a straightforward adjustment to existing pulse fluence limits to enhance protection consistency against excessive temperature increases, irrespective of pulse duration and frequency. Limitations and Further Risks - ⚠ Nonthermal hazards and thermoacoustic effects—produced by brief, extremely high amplitude RF-EMF pulses—are not addressed in this analysis, despite the potential for biological impacts due to rapid temperature changes, even if absolute temperature increases are small. Conclusion & Research Needs ⚠ The current guidelines exhibit inconsistencies in safeguarding against transient heating. Further research and development are urgently needed to establish and refine exposure limits for pulsed RF-EMF to ensure adequate health protection.

AI evidence extraction

Main findings

ICNIRP and IEEE (C95.1-2019) brief-exposure limits for 6–300 GHz were evaluated using numerical and analytical approaches with a one-dimensional thermal tissue model. The analysis of rectangular pulses and impulsive energy events found that the guidelines provide varying levels of protection against transient skin heating, with IEEE described as more conservative than ICNIRP. The paper proposes an adjustment to pulse fluence limits to improve consistency of protection against excessive temperature increases across pulse duration and frequency.

Outcomes measured

• transient skin heating
• temperature increase in tissue (thermal effects)
• consistency/protectiveness of exposure limits for brief/pulsed RF-EMF

Limitations

• Analysis focused on thermal effects using a one-dimensional thermal tissue model.
• Nonthermal hazards and thermoacoustic effects from extremely high amplitude brief pulses were not addressed.

Suggested hubs

• who-icnirp (0.9)
  Directly evaluates ICNIRP limits and compares them with IEEE guidelines for brief RF exposures.
• 5g-policy (0.75)
  Discusses 6–300 GHz brief/pulsed exposures and base-station MIMO beamforming scenarios relevant to 5G/mmWave exposure guidance.

{
    "study_type": "engineering",
    "exposure": {
        "band": "RF/mmWave",
        "source": "cellular base station (MIMO beamforming); pulsed RF-EMF",
        "frequency_mhz": null,
        "sar_wkg": null,
        "duration": "brief exposures within a 6-minute averaging period; pulsed high peak power/low duty cycle"
    },
    "population": null,
    "sample_size": null,
    "outcomes": [
        "transient skin heating",
        "temperature increase in tissue (thermal effects)",
        "consistency/protectiveness of exposure limits for brief/pulsed RF-EMF"
    ],
    "main_findings": "ICNIRP and IEEE (C95.1-2019) brief-exposure limits for 6–300 GHz were evaluated using numerical and analytical approaches with a one-dimensional thermal tissue model. The analysis of rectangular pulses and impulsive energy events found that the guidelines provide varying levels of protection against transient skin heating, with IEEE described as more conservative than ICNIRP. The paper proposes an adjustment to pulse fluence limits to improve consistency of protection against excessive temperature increases across pulse duration and frequency.",
    "effect_direction": "mixed",
    "limitations": [
        "Analysis focused on thermal effects using a one-dimensional thermal tissue model.",
        "Nonthermal hazards and thermoacoustic effects from extremely high amplitude brief pulses were not addressed."
    ],
    "evidence_strength": "low",
    "confidence": 0.7399999999999999911182158029987476766109466552734375,
    "peer_reviewed_likely": "yes",
    "keywords": [
        "RF-EMF",
        "exposure limits",
        "pulsed radiofrequency",
        "brief exposures",
        "thermal effects",
        "skin heating",
        "ICNIRP",
        "IEEE C95.1-2019",
        "pulse fluence limits",
        "MIMO",
        "beamforming",
        "6–300 GHz"
    ],
    "suggested_hubs": [
        {
            "slug": "who-icnirp",
            "weight": 0.90000000000000002220446049250313080847263336181640625,
            "reason": "Directly evaluates ICNIRP limits and compares them with IEEE guidelines for brief RF exposures."
        },
        {
            "slug": "5g-policy",
            "weight": 0.75,
            "reason": "Discusses 6–300 GHz brief/pulsed exposures and base-station MIMO beamforming scenarios relevant to 5G/mmWave exposure guidance."
        }
    ]
}
